RA SMA Male Connector Crimp/Solder Attachment For RG58 Cable

RA SMA Male Connector Crimp/Solder Attachment For RG58 Cable

SC6058 RA SMA male coaxial connector from Fairview Microwave has an interface type of RG58 and a 50 Ohm impedance. This SMA male connector uses crimp/solder shield attachment and crimp/solder contact ...

SC6058 RA SMA male coaxial connector from Fairview Microwave has an interface type of RG58 and a 50 Ohm impedance. This SMA male connector uses crimp/solder shield attachment and crimp/solder contact attachment methods. Our male SMA right angle coaxial connector provides a minimum frequency of DC and a maximum frequency of 12.4 GHz.Right angle SMA male coaxial RF connector has a ptfe dielectric type and a VSWR of 1.3:1. This Fairview Microwave SMA coaxial connector has a stainless steel body with gold plating. Our SC6058 SMA RA connector uses brass contact and a gold plating material. This SMA male right angle coaxial RF connector is RoHS compliant, you can find this SMA male right angle coaxial connector datasheet specifications above. Fairview Microwave RA male SMA connector purchases will ship the same day. Our SMA right angle male RG58 connector is part of over one million RF, microwave and millimeter wave components in stock and ready for same-day shipment worldwide. We also build custom SMA cable connector assemblies that will ship quickly from our Allen, TX location in the.

Expand

SKU SC6058 -0

QTY available

Price

Quantity Price

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

Polarity

Standard

Connector Series

SMA

Connector Gender

Male

Impedance

50 Ohm

Body Style

Right Angle

Attachment Method

Crimp/Solder

Mount Method

None

Minimum Frequency

DC

Maximum Frequency

12.4 GHz

Termination Type

Coax

Interface Type 1

RG58

Product compliance

RoHS status

Not Available

REACH status

Not Available

TSCA status

Not Available

ECCN

Not Available

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
