RA RP TNC Female Bulkhead PCB Connector Surface Mount Solder Attachment IP67 Rated

RA RP TNC Female Bulkhead PCB Connector Surface Mount Solder Attachment IP67 Rated

SC9702 RA RP TNC female bulkhead PCB connector from Fairview Microwave has an interface type of surface mount and a 50 Ohm impedance. This reverse polarity TNC female bulkhead connector uses solder sh...

SC9702 RA RP TNC female bulkhead PCB connector from Fairview Microwave has an interface type of surface mount and a 50 Ohm impedance. This reverse polarity TNC female bulkhead connector uses solder shield attachment and solder contact attachment methods. Our reverse polarity female TNC right angle PCB connector provides a minimum frequency of DC and a maximum frequency of 3 GHz.Reverse polarity right angle TNC female bulkhead PCB RF connector has a ptfe dielectric type and a VSWR of 1.3:1. This Fairview Microwave TNC PCB connector has a brass body with gold plating. Our SC9702 RP-TNC RA connector uses beryllium copper contact and a gold plating material. This reverse polarity TNC female right angle bulkhead PCB RF connector is RoHS and IP67 rated compliant, you can find this reverse polarity TNC female right angle bulkhead PCB IP67 rated connector datasheet specifications above. Fairview Microwave RP RA female TNC bulkhead connector purchases will ship the same day. Our bulkhead TNC reverse polarity right angle female surface mount connector is part of over one million RF, microwave and millimeter wave components in stock and ready for same-day shipment worldwide. We also build custom RP-TNC cable connector assemblies that will ship quickly from our Allen, TX location in the.

Expand

SKU SC9702 -0

QTY available

Price

Quantity Price

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

Polarity

Reverse Polarity

Connector Series

TNC

Connector Gender

Female

Impedance

50 Ohm

Body Style

Right Angle

Attachment Method

Solder

Mount Method

Bulkhead

Minimum Frequency

DC

Maximum Frequency

3 GHz

Termination Type

PCB

Interface Type 1

Surface Mount

Product compliance

RoHS status

Substance(s) Present Above Threshold with Exemption

REACH status

SVHC (06/2024) Substance(s) Present Above Threshold

TSCA status

No Substance(s) Present Above Threshold

ECCN

Not Available

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
