RA TNC Male Connector Clamp/Solder Attachment for LL160 Cable

RA TNC Male Connector Clamp/Solder Attachment for LL160 Cable

FMCN1470-4MJR5 TNC male right angle coaxial connector has an interface type of TNC male LL160 and has an impedance of 50 Ohm. Fairview Microwave's TNC male connector uses clamp/solder as an attachme...

FMCN1470-4MJR5 TNC male right angle coaxial connector has an interface type of TNC male LL160 and has an impedance of 50 Ohm. Fairview Microwave's TNC male connector uses clamp/solder as an attachment method. Our male TNC right angle coaxial connector operates at a maximum frequency of 18 GHz. This TNC male RF connector is stocked to be readily available for same business day shipment.The Fairview Microwave right angle TNC male (plug) coaxial connector has a PTFE dielectric type and a VSWR of 1.16:1. Fairview Microwave's TNC coaxial connector has a passivated stainless steel body. Our FMCN1470-4MJR5 right angle connector uses beryllium copper contact. This threaded RF connector can operate at temperatures ranging from -65 to +165 degrees C. Additional RF connector specs and dimensions for this component can be found on its PDF specification datasheet and CAD drawings. This right angle TNC connector has a gold inner contact plating. Fairview Microwave’s standard TNC male connector has a dielectric withstanding voltage of 1,000 Vrms. This connector comes with a minimum insulation resistance of MOhms. This Fairview Microwave standard right angle male TNC connector will ship the same business day as purchased. Our TNC right angle male connector is part of RF, microwave and millimeter wave components in stock for worldwide shipment. For further information on similar products, our expert technical support and trained sales team can get you the ideal RF connector as per your requirements.

Expand

SKU FMCN1470-4MJR5 -0

QTY available

Price

Quantity Price

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Polarity

Standard

Connector Series

TNC

Connector Gender

Male

Impedance

50 Ohm

Body Style

Right Angle

Attachment Method

Clamp/Solder

Mount Method

None

Minimum Frequency

DC

Maximum Frequency

18 GHz

Termination Type

Coax

Interface Type 1

LL160

Product compliance

RoHS status

Not Available

REACH status

Not Available

TSCA status

Not Available

ECCN

Not Available

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
