698-960 MHz / 1710-2700 MHz / 3400-4200 MHz Low PIM Rated VH-pol MIMO Panel Antenna, 5-7 dBi, Wall Mount, 2 x Type N Female Connector

Due to this products weight or size, it will be shipped via Freight. Freight

698-960 MHz / 1710-2700 MHz / 3400-4200 MHz Low PIM Rated VH-pol MIMO Panel Antenna, 5-7 dBi, Wall Mount, 2 x Type N Female Connector

The wall mount MIMO panel FM51FP1014 antenna from Fairview Microwave is a high performance, low PIM rated RF component which operates from 698 to 4200 MHz. The FM51FP1014 antenna is ideal for 5G, LTE,...

The wall mount MIMO panel FM51FP1014 antenna from Fairview Microwave is a high performance, low PIM rated RF component which operates from 698 to 4200 MHz. The FM51FP1014 antenna is ideal for 5G, LTE, CDMA, LPWAN/IoT/M2M applications including LoRA, LTE-M, NB-IOT and Distributed Antenna System (DAS) Networks. The Multi-Band design of the Fairview Microwave FM51FP1014 antenna can be used for a wide array of in-building wireless applications where wide coverage is desired. Fairview Microwave's FM51FP1014 can be used to distribute Cellular and WiFi signals throughout a building or area. The Type N connectorized FM51FP1014 antenna with V/H polarization from Fairview Microwave provides Passive Intermodulation (PIM) ratings better than -150 dBc. The key to providing the best performance in telecommunications is to ensure the components used are low PIM rated. The 698-4200 MHz FM51FP1014 with 7 dBi max gain helps meet the increasing demand for higher data rates and the ability to provide streaming video for mobile devices.The Type N connectorized FM51FP1014 antenna from Fairview Microwave excels in large open areas such as indoor courtyards, indoor sporting venues, convention centers and shopping malls. The mounting bracket and hardware are included for easy installation. Fairview Microwave wall mount MIMO panel with Type N female purchases will ship the same day. Our FM51FP1014 antenna is part of over one million RF, microwave and millimeter wave components in stock and ready for same-day shipment worldwide.

Expand

SKU FM51FP1014 FM51FP1014 -0

QTY available 9

Price $70.99

Quantity Price

1-9$70.99

10-24$68.15

25-99$65.31

100-249$62.47

250-499$59.63

500+$59.63Please call for quote

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

Antenna Type

Panel

Design Type

Low PIM

Direction Type

Directional

Band Type

Wide

Polarization

Vertical/Horizontal

Number of Ports

2

Minimum Frequency

698 MHz

Maximum Frequency

4.2 GHz

Connector Series

N

Connector Gender

Female

Impedance

50 Ohm Ohm

Nominal Gain

5 dBi

Max Input Power

100

Product compliance

RoHS status

Not Available

REACH status

Not Available

TSCA status

Not Available

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
