TNC Male to BNC Male Adapter

TNC Male to BNC Male AdapterFairview MicrowaveFMAD9181

TNC Male to BNC Male Adapter

The TNC to BNC adapter FMAD9181 from Fairview Microwave is part of a very large in-stock collection of RF interconnect components. Our threaded TNC to threaded BNC RF adapter comes with a 50 Ohm imped...

The TNC to BNC adapter FMAD9181 from Fairview Microwave is part of a very large in-stock collection of RF interconnect components. Our threaded TNC to threaded BNC RF adapter comes with a 50 Ohm impedance. This adapter is manufactured to precise RF component specifications and has a maximum VSWR of 1.3:1. This TNC to BNC adapter is constructed with the male gender on side 1 and the male gender on side 2. The TNC male to BNC male coaxial adapter from Fairview Microwave has a straight body style. Our RF adapter can be utilized to protect connectors on expensive equipment where the number of connect and disconnect cycles is high. The FMAD9181 adapter has a length of 0.57 inches, a width of 0.57 inches, and a weight of 0.45 lbs. Our between series RF adapter operates at a maximum frequency of 4 GHz. This TNC male to BNC male radio frequency adapter has a brass connector body with nickel body plating. The Fairview Microwave FMAD9181 coaxial RF adapter operates at temperatures ranging from -65 to 165 degrees C. Additional dimensions and specifications for this adapter are on our downloadable PDF datasheet above. Fairview Microwave’s TNC male to BNC male adapter is part of over one million RF, microwave and millimeter wave components in stock for worldwide shipment. We also stock and custom-build TNC to BNC coaxial cables that ship quickly from our facility for all your RF adapter component needs. Make your online purchase right now to take advantage of our same-business-day shipping. For further information on similar products, our expert technical support and trained sales team can get you the ideal 4 GHz radio frequency adapter as per your requirements.

SKU FMAD9181 FMAD9181 -0

QTY available 35

Price $33.89

Quantity Price

1-24$33.89

25-49$32.20

50-99$30.50

100-249$29.15

250-499$27.79

500+$27.79Please call for quote

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Key specifications

Datasheet

Connector Series 1

TNC

Connector Gender 1

Male

Connector Polarity 1

Standard

Connector Impedance 1

50 Ohm

Connector Series 2

BNC

Connector Gender 2

Male

Connector Polarity 2

Standard

Connector Impedance 2

50 Ohm

Frequency, Min

DC

Frequency, Max

4 GHz

Adapter Body Style

Straight

Connector Mount Method 1

None

Connector Body Material 1

Brass

Connector Body Plating 1

Nickel

Connector Mount Method 2

None

Connector Body Material 2

Brass

Connector Body Plating 2

Nickel

Product compliance

Product compliance

RoHS status

Not Available

REACH status

Not Available

TSCA status

Not Available

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
