High Frequency Flexible Coax Cable Double Shielded with Blue FEP Jacket

High Frequency Flexible Coax Cable Double Shielded with Blue FEP Jacket

FM-P047 coaxial cable from Fairview Microwave is only one of many radio frequency coaxial cable types specifically stocked to be ready for same business day shipment. Fairview Microwave’s FM-P047HF-BU...

FM-P047 coaxial cable from Fairview Microwave is only one of many radio frequency coaxial cable types specifically stocked to be ready for same business day shipment. Fairview Microwave’s FM-P047HF-BULK coaxial cable is manufactured in a flexible design and has a 50 Ohm impedance. This flexible 50 Ohm coaxial cable is constructed with an FEP jacket of 0.06-inch diameter. Fairview Microwave’s FM-P047HF-BULK flexible coaxial cable with an FEP jacket is rated for a 110 GHz maximum operating frequency. This 50 Ohm flexible coaxial cable is built with a shield count of 2 and RF shielding of 90 dB. Our RF coaxial cable has a solid conductor of copper with silver plating. Our blue-colored coaxial RF cable has a typical insertion loss/attenuation of 24.41, 35.02, 62.76, 89.93, 131.62, 168.18, 211.66, 241.9, 277.48 and 377.02 dB/100ft at frequency of 500 MHz, 1 GHz, 3 GHz, 6 GHz, 12 GHz, 18 GHz, 26.5 GHz, 32 GHz, 40 GHz and 65 GHz respectively. The FM-P047 coaxial cable with PTFE dielectric can operate at temperatures ranging from -65 to +165 degrees C. Additional specifications for this FM-P047HF-BULK double-shielded RF coaxial cable are on our downloadable PDF datasheet above. Our blue-colored flexible RF cable with 50 Ohm impedance has 35.02 dB/100ft of attenuation at 1 GHz. This standard-rated coaxial cable features a dual shield of silver plated copper braid over the silver plated copper tape. This RF cable has a repeat minimum bend radius of 0.1 inch.FM-P047 RF cable is part of more than one million RF, microwave, and millimeter wave parts in stock at Fairview Microwave. This FM-P047 coaxial cable is ready to buy and can be shipped worldwide. Fairview Microwave also maintains a wide selection of other radio frequency coaxial cable types that ship the same business day from our warehouse in the United States, as with the rest of our other RF/microwave and millimeter wave components.

Expand

SKU FM-P047HF-BULK FM-P047HF-BULK -0

QTY available

Price

Quantity (FEET) Price

All prices are in US dollars and do not include duties.
Quantity selected indicates total length of bulk cable (i.e., inputting 10 indicates a 10 foot section), contact us for alternate requirements.
Contact us for different unit of measure (inches, meters, etc.) requirements.

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

Generic Name

Version of 047 Semi-rigid

Flex Type

Flexible

Impedance

50 Ohm

Dielectric Type

PTFE

Velocity of Propagation

70 %

Jacket Diameter

0.06 in

Jacket Material

FEP

No. of Shields

2

Attenuation at 1 Ghz.

35.02 dB

RF Shielding

90 dB

Frequency, Max

110 GHz

Max Operating Temperature

165 deg C

Center Conductor Type

Solid

Inner Conductor, Number of Strands

1

Minimum Bend Radius, Repeated

0.1 in

Coax Type

Coax

Product compliance

RoHS status

Not Available

REACH status

Not Available

TSCA status

Not Available

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
