Low Loss Flexible LMR-195-LLPX Outdoor Rated Coax Cable Double Shielded with Orange PVC (FR) Jacket

Low Loss Flexible LMR-195-LLPX Outdoor Rated Coax Cable Double Shielded with Orange PVC (FR) Jacket

Name: Low Loss Flexible LMR-195-LLPX Outdoor Rated Coax Cable Double Shielded with Orange PVC (FR) Jacket
Brand: Fairview Microwave, Inc.
SKU: LMR-195-LLPX
Price: 4.2315 USD
Availability: InStock

LMR-195-LLPX-BULK low-loss coaxial cable from Fairview Microwave is only one of many radio frequency coaxial cable types specifically stocked to be ready for same business day shipment. Fairview Micro...

LMR-195-LLPX-BULK low-loss coaxial cable from Fairview Microwave is only one of many radio frequency coaxial cable types specifically stocked to be ready for same business day shipment. Fairview Microwave’s LMR-195-LLPX coaxial cable is manufactured in a flexible design and has a 50 Ohm impedance. This flexible 50 Ohm coaxial cable is constructed with a PVC (FR) jacket of 0.195-inch diameter. Our RF coaxial cable is ideal for indoor/outdoor plenum feeder runs , drop in replacement for rg-142 , ul/nec/csa rated cmp/ft6 and any wireless application. Fairview Microwave’s LMR-195-LLPX flexible coaxial cable with a PVC (FR) jacket is rated for a 8 GHz maximum operating frequency. This 50 Ohm flexible coaxial cable is built with a shield count of 2 and RF shielding of 90 dB. Our low-loss RF coaxial cable has a solid conductor of copper. Our orange-colored coaxial RF cable has a typical insertion loss/attenuation of 2.5, 4.4, 5.3, 7.8, 10.9, 14.1, 15.4, 18.3, 28.2 and 35.7 dB/100ft at frequency of 50 MHz, 150 MHz, 220 MHz, 450 MHz, 900 MHz, 1.5 GHz, 1.8 GHz, 2.5 GHz, 5.8 GHz and 8 GHz respectively. The LMR-195-LLPX-BULK coaxial cable with PTFE (LD) dielectric can operate at temperatures ranging from -40 to +125 degrees C. Additional specifications for this LMR-195-LLPX double-shielded RF coaxial cable are on our downloadable PDF datasheet above. Our orangeflexible RF cable with 50 Ohm impedance has 11.8 dB/100ft of attenuation at 1 GHz. This outdoor-rated coaxial cable features a dual shield of tinned copper braid over the aluminum tape. Our low-loss coaxial cable has a dielectric withstanding voltage of 1,000 Vdc. This low-loss RF cable has a one time minimum bend radius of 0.5 inches and a repeat minimum bend radius of 2 inches. Our flexible 50 Ohm coaxial cable has a peak power rating of 2,500 watts. LMR-195-LLPX-BULK low-loss RF cable is part of more than one million RF, microwave, and millimeter wave parts in stock at Fairview Microwave. This LMR-195-LLPX-BULK coaxial cable is ready to buy and can be shipped worldwide. Fairview Microwave also maintains a wide selection of other radio frequency coaxial cable types that ship the same business day from our warehouse in the United States, as with the rest of our other RF/microwave and millimeter wave components.* LMR™ is a trademark of Times Microwave Systems.

Expand

SKU LMR-195-LLPX LMR-195-LLPX -0

QTY available

Price

Quantity (FEET) Price

All prices are in US dollars and do not include duties.
Quantity selected indicates total length of bulk cable (i.e., inputting 10 indicates a 10 foot section), contact us for alternate requirements.
Contact us for different unit of measure (inches, meters, etc.) requirements.

Product available until inventory is depleted

This product has been discontinued and has availability until the inventory is depleted. Please contact our customer service team for assistance in identifying the appropriate replacement part for your application.

Custom length

Unit

Minimum 6 inches

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Lengths are rounded up to the nearest quarter inch or centimeter respectively.

Key specifications

Datasheet

View All

Generic Name

LMR-195-LLPX

Flex Type

Flexible

Impedance

50 Ohm

Dielectric Type

PTFE (LD)

Velocity of Propagation

80 %

Jacket Diameter

0.195 in

Jacket Material

PVC (FR)

No. of Shields

2

Attenuation at 1 Ghz.

11.8 dB

RF Shielding

90 dB

Frequency, Max

8 GHz

Max Operating Temperature

125 deg C

Center Conductor Type

Solid

Inner Conductor, Number of Strands

1

Minimum Bend Radius, One Time

0.5 in

Minimum Bend Radius, Repeated

2 in

Coax Type

Coax

Product compliance

RoHS status

Not Available

REACH status

Not Available

TSCA status

Not Available

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
