BNC Female (Jack) Bulkhead Isolated Ground Connector Solder Cup Terminal, .350 inch D Hole, Solder

BNC Female (Jack) Bulkhead Isolated Ground Connector Solder Cup Terminal, .350 inch D Hole, Solder

FMCN1353 BNC female bulkhead isolated ground terminal connector from Fairview Microwave has an interface type of solder cup and a 50 Ohm impedance. This BNC female bulkhead connector uses shield attac...

FMCN1353 BNC female bulkhead isolated ground terminal connector from Fairview Microwave has an interface type of solder cup and a 50 Ohm impedance. This BNC female bulkhead connector uses shield attachment of solder attachment for the contact. Our female BNC terminal connector provides a minimum frequency of DC and a maximum frequency of 1 GHz.BNC female bulkhead isolated ground terminal RF connector has a ptfe dielectric type and a VSWR of 1.3:1. This Fairview Microwave BNC terminal connector has a brass body with nickel plating. Our FMCN1353 BNC connector uses brass contact and a nickel plating material. This BNC female bulkhead isolated ground terminal RF connector is RoHS compliant, you can find this BNC female bulkhead isolated ground terminal connector datasheet specifications above.Fairview Microwave female BNC bulkhead connector purchases will ship the same day. Our bulkhead BNC female solder cup connector is part of over one million RF, microwave and millimeter wave components in stock and ready for same-day shipment worldwide. We also build custom BNC cable connector assemblies that will ship quickly from our location.

Expand

SKU FMCN1353 FMCN1353 -0

QTY available 130

Price $14.39

Quantity Price

1-24$14.39

25-49$13.67

50-99$12.95

100-249$12.38

250-499$11.80

500+$11.80Please call for quote

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

Polarity

Standard

Connector Series

BNC

Connector Gender

Female

Impedance

50 Ohm

Body Style

Straight

Attachment Method

Solder

Mount Method

Bulkhead

Minimum Frequency

DC

Maximum Frequency

1 GHz

Termination Type

Terminal

Interface Type 1

Solder Cup

Product compliance

RoHS status

Substance(s) Present Above Threshold with Exemption

REACH status

SVHC (01/2025) Substance(s) Present Above Threshold

TSCA status

No Substance(s) Present Above Threshold

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
