Biased Detector With SMA Male to SMA Female and Negative Video Out Operating From 18 GHz to 26 GHz

Biased Detector With SMA Male to SMA Female and Negative Video Out Operating From 18 GHz to 26 GHz

RF dectector FMMT1009 from Fairview is only one component of a large number of radio frequency parts specifically stocked to be readily available for rapid shipment. The Fairview Microwave radio frequ...

RF dectector FMMT1009 from Fairview is only one component of a large number of radio frequency parts specifically stocked to be readily available for rapid shipment. The Fairview Microwave radio frequency detector is manufactured as a biased design and has a 50 Ohm impedance. Our RF biased detector is constructed with SMA male to SMA female connectors.Fairview Microwave SMA to SMA biased detector has a minimum frequency of 18 GHz and a maximum frequency of 26 GHz. This SMA coaxial RF biased detector part number FMMT1009 has a maximum input power of 23 dBm and a video capacitance of 5 pF. Additional RF specs for this Fairview Microwave component can be found on its radio frequency detector datasheet PDF specifications above.Our RF connectorized detector is only one of more than 1 million RF, microwave and millimeter wave parts we stock. This coaxial biased SMA to SMA detector is ready to buy and be shipped worldwide. Fairview also stocks a wide selection of other radio frequency coaxial detector products that ship same-day from our warehouse along with rest of our RF, microwave and millimeter wave components.

Expand

SKU FMMT1009 FMMT1009 -0

QTY available Call us

Price $193.65

Quantity Price

1-4$193.65

5-9$185.90

10-24$178.16

25-99$170.41

100-249$162.67

250+$162.67Please call for quote

All Prices are in US Dollars and do not include duties

Quantity

Key specifications

Datasheet

View All

Biased Detector or Zero Biased Detector

Biased

Minimum Frequency

18 GHz

Maximum Frequency

26 GHz

Detector Polarity

Negative

Tangential Sensitivity, Max

-52 dBm

Power, Max Input

23 Watts

Connector In Series

SMA

Connector-In Group (Threaded, Bayonet)

Threaded

Connector In Gender

Male

Connector Out Series

SMA

Connector-Out Group (Threaded, Bayonet)

Threaded

Connector Out Gender

Female

Min Operating Temperature

-55 deg C

Max Operating Temperature

125 deg C

Product compliance

RoHS status

No Substance(s) Present Above Threshold

REACH status

SVHC (01/2025) No Substance(s) Present Above Threshold

TSCA status

No Substance(s) Present Above Threshold

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
