High Power Limiter, SMA, 100W Peak Power, 10 ns Recovery, 14 dBm Flat Leakage, 500 MHz to 18 GHz

High Power Limiter, SMA, 100W Peak Power, 10 ns Recovery, 14 dBm Flat Leakage, 500 MHz to 18 GHz

Fairview Microwave’s SML-0518-01-14-SMA is a high power broadband signal limiter that ships same day worldwide. High power limiter SML-0518-01-14-SMA has SMA female to SMA female type connectors with ...

Fairview Microwave’s SML-0518-01-14-SMA is a high power broadband signal limiter that ships same day worldwide. High power limiter SML-0518-01-14-SMA has SMA female to SMA female type connectors with a compact and rugged, thin-film construction. This SMA series limiter has a maximum peak power of 100W at 1us pulse, 0.1% Duty Cycle and we keep it in-stock constantly. The SML-0518-01-14-SMA SMA to SMA limiter has a typical recovery time of 10 ns. This industry-leading 100W high power limiter features a maximum insertion loss of 2 dB.SML-0518-01-14-SMA 2 dB limiter with 100W max power, has a minimum operational temperature range of -54 degrees C to a maximum of 85°C. Off-the-shelf online or by phone, we ship these high-quality SMA to SMA limiters with a broadband frequency of 500 MHz – 18 GHz around the globe. Our 100W high power limiter at 1us pulse, 0.1% Duty Cycle has a 10 ns recovery time and is intended for use in applications like microwave radio, VSAT, SATCOM, radar and space systems.18 GHz 100W high-reliability limiter meets US Department of Defense environmental test methods for vibration of MIL-STD-202F, METHOD 204D COND. B and a humidity of MIL-STD-202F, METHOD 103B COND. B. Fairview Microwave’s high power 10 ns RF limiter has an average input power of 1 and a military grade package design. Contact Fairview Microwave’s expert technical support for assistance with SML-0518-01-14-SMA high power 85°C broadband limiter. Download our 100W high power SML-0518-01-14-SMA PDF datasheet with specifications and CAD drawing with dimensions for details. Our knowledgeable sales team simplifies the purchasing process and ensures that your SMA female to SMA female power limiter will be exact to spec.Fairview Microwave was founded in 1992 and has since become reputable suppliers for 500 (MHz) – 18 (GHz) high power 2/1.5 insertion loss limiters and electronic components. Limiter SML-0518-01-14-SMA by Fairview Microwave has a max leakage of 14 dBm and is just one of more than 1 million RF, microwave and limiter parts we stock. This SMA female to female 1W average power limiter is ready to buy and can be shipped worldwide. Order your high power 100W limiter online today; there is no MOQ (minimum order quantity) and we provide same-day shipping.

Expand

SKU SML-0518-01-14-SMA SML-0518-01-14-SMA -0

QTY available

Price

Quantity Price

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

Connector In Series

SMA

Connector In Gender

Female

Connector In Impedance

50 Ohm

Connector Out Series

SMA

Connector Out Gender

Female

Minimum Frequency

500 MHz

Maximum Frequency

18 GHz

Maximum Insertion Loss

2 dB

Design Type

High Power

Peak Power

100 Watt

Leakage (CW)

14 dBm

Recovery Time

10 ns

Product compliance

RoHS status

No Substance(s) Present Above Threshold

REACH status

SVHC (01/2025) No Substance(s) Present Above Threshold

TSCA status

No Substance(s) Present Above Threshold

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
