Calibrated Noise Source Module With a Noise Output ENR of 15 dB, and a Voltage of +28 VDC, Operating From 0.01 MHz to 2 GHz With SMA

Calibrated Noise Source Module With a Noise Output ENR of 15 dB, and a Voltage of +28 VDC, Operating From 0.01 MHz to 2 GHz With SMA

FMNG1000 is a coaxial packaged Noise Source module which operates over a wide frequency range from 10 KHz to 2 GHz. The design is calibrated for 10, 100, 1000, and 2000 MHz frequencies and is ideal f...

FMNG1000 is a coaxial packaged Noise Source module which operates over a wide frequency range from 10 KHz to 2 GHz. The design is calibrated for 10, 100, 1000, and 2000 MHz frequencies and is ideal for Noise Figure measurements and a variety of built-in test applications. This model operates at +28 Vdc and features an ENR level of 15 dB min, typical flatness across the entire frequency band is +/- 0.5 dB, and excellent stability. Performance is specified over -55°C to +85°C with Noise Output Temperature Variation <0.01 dB/°C, Noise Output Variation <0.1 dB/%V. The rugged package design supports an output Female SMA connector with an EMI/RFI filter voltage pin and ground tab. Additionally, the model is designed to meet a variety of demanding MIL-STD-202F environmental test conditions including Humidity, Thermal Shock, and Vibration for added confidence for highly reliable operation.

Expand

SKU FMNG1000 FMNG1000 -0

QTY available

Price

Quantity Price

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

DC Input Connector Series

Impedance

50 Ohm

RF Output Connector Series

SMA

RF Output Gender

Female

Minimum Frequency

0.01 MHz

Maximum Frequency

2 GHz

Bias Voltage

30 Volts

Product compliance

RoHS status

No Substance(s) Present Above Threshold

REACH status

SVHC (01/2025) No Substance(s) Present Above Threshold

TSCA status

No Substance(s) Present Above Threshold

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
