10 dB WR-28 Waveguide Broadwall Coupler with UG-599/U Square Cover Flange and H-Plane Coupled Port from 26.5 GHz to 40 GHz in Brass Copper

10 dB WR-28 Waveguide Broadwall Coupler with UG-599/U Square Cover Flange and H-Plane Coupled Port from 26.5 GHz to 40 GHz in Brass Copper

The Fairview Microwave WR-28 waveguide coupler has a nominal coupling level of 10 dB and is in stock for same-day shipment worldwide. High-quality WR-28 waveguide broadwall couplers from Fairview Micr...

The Fairview Microwave WR-28 waveguide coupler has a nominal coupling level of 10 dB and is in stock for same-day shipment worldwide. High-quality WR-28 waveguide broadwall couplers from Fairview Microwave are equipped with a brass copper UG-599/U square cover and gold-plated flanges. Our WR-28 waveguide 3-port coupler with UG-599/U square cover H-plane flanges operate up to a maximum frequency of 40 GHz. The Fairview Microwave FMW28CP011-10 precision microwave coupler at a 10 dB typical coupling value is manufactured with a a brass copper body plated in gold, providing industry-leading electrical performance. These directional broadwall 3-port waveguide couplers that operate from 26.5 to 40 GHz are directional components that are used in various applications like radar, test benches, satellites, and more. Fairview Microwave’s expert technical support is available on this FMW28CP011-10 a brass copper coupler as well as on over 1,000,000 other products. The datasheet for this Fairview Microwave WR-28 10 dB UG-599/U flanged waveguide coupler is available in PDF format with a CAD drawing, dimensions, and specifications, which can be found above for download. Our ideal 3-port gold-plated broadwall couplers has a maximum insertion loss of 0.8 dB. Fairview Microwave’s WR-28 a brass copper waveguide directional broadwall coupler has a maximum main line VSWR of 1.1:1 and a maximum secondary line VSWR of 1.25:1. Our WR-28 waveguide couplers have a minimum directivity value of 35 dB. This waveguide broadwall coupler has a length of 5.91 inches, height of 0.75 inches, and weighs 1.75 lbs. The Fairview Microwave has supplied state-of-the-art RF components like these 10 dB nominal coupling value broadwall waveguide couplers with UG-599/U flanges since 1992. This a brass copper WR-28 waveguide is just one component of a large family of over 220 waveguide couplers that Fairview Microwave offers with simple purchasing, immediate shipping worldwide, and expert tech support always on hand. The Fairview Microwave website is where you can find our UG-599/U flanged WR-28 waveguide coupler as well as other waveguide components, purchase online or contact our knowledgeable sales team now for further details.

Expand

SKU FMW28CP011-10 FMW28CP011-10 -0

QTY available

Price

Quantity Price

All Prices are in US Dollars and do not include duties

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Key specifications

Datasheet

View All

Waveguide Size

WR-28

Flange Size

UG-599/U Flange

Flange Type

Square Cover Flange

Flange Group

Standard

Minimum Frequency

26.5 GHz

Maximum Frequency

40 GHz

Maximum VSWR

1.25:1

Maximum Insertion Loss

0.8 dB

Coupling

10 dB
