Low Loss RA TNC Male to RA SMB Plug Cable LMR-195-UF Coax

Low Loss RA TNC Male to RA SMB Plug Cable LMR-195-UF Coax

RF cable assembly part number FMCA100288 from Fairview Microwave is just one of a huge selection of coaxial cables for radio, antenna and interconnect with RF components. Fairview Microwave RF coaxi...

RF cable assembly part number FMCA100288 from Fairview Microwave is just one of a huge selection of coaxial cables for radio, antenna and interconnect with RF components. Fairview Microwave RF coaxial cable assembly products are designed for typical use, production, laboratory test and measurement, defense/military, aerial antenna towers, etc. The 50 Ohm FMCA100288 cable assembly, like our other coaxial cable assemblies, is specifically ready for quicker shipment than most in the industry can provide. This Fairview Microwave RF coaxial assembly is manufactured with a TNC cable connection on one end and a SMB cable connection on the other end. Our TNC to SMB cable assembly has a male (plug) gender on end one and plug on end two. Cable assembly FMCA100288 is built in a male to plug coaxial assembly design and will ship quickly after the purchase. This black RF cable assembly has a TPE jacket with a 0.195-inch diameter. This low loss RF cable assembly operates at a maximum frequency of 4 GHz. Our cable assemblies are constructed using durable and flexible materials with a 2-inch bend radius to withstand repetitive movements, ensuring reliable performance over extended periods. The minimum bend radius for flexible cable assemblies is 0.5 inch, allowing for a single bend without damaging the cable. The FMCA100288 right angle TNC male to right angle SMB plug RF cable assembly from Fairview Microwave has a maximum VSWR of 1.4:1. This between series cable assembly can withstand temperatures ranging from -40 to 85 deg C. Our low loss RF cable comes with a minimum RF shielding of 90 dB. Fairview Microwave’s TNC male to SMB plug cable assembly FMCA100288 is built with LMR-195-UF coax and it is a flexible coax design. Our low loss cable assembly is manufactured with TNC to SMB cable connectors and has a 50 Ohm impedance. One connector features the clamp/solder attachment method and a brass body with nickel plating. While the other has the crimp/solder attachment method and a brass body with nickel plating. This RF cable assembly with a 0.5-inch diameter has copper as the cable’s inner conducting material and Foam PE dielectric type. Additional dimensions, specifications and CAD drawings for this FMCA100288 low loss RF cable are available on our downloadable PDF datasheet. TNC right angle male to SMB right angle plug coaxial cable assembly is just one of more than a million RF parts we have available. Fairview Microwave is where to buy a high quality TNC to SMB cable assembly for quick shipment worldwide. We also have a wide selection of other low to high frequency coaxial cables that will ship quickly from our United States warehouse. Because Fairview Microwave is one of a few RF, microwave and millimeter wave cable assembly suppliers with rapid shipping, many variations of TNC and SMB cable assemblies can also be built and shipped quickly as well. For further information on similar products, our expert technical support and trained sales team can get you the ideal TNC to SMB low loss RF cable assembly as per your requirements.* LMR™ is a trademark of Times Microwave Systems.

Expand

SKU FMCA100288 FMCA100288 -0

Length

Or custom length

Unit

Minimum 6 inches

Quantity

Confirm shipment date

Ship as soon as

Please enter a valid U.S. postal code

Lengths are rounded up to the nearest quarter inch or centimeter respectively.

Key specifications

Datasheet

View All

Connector Series 1

TNC

Connector Gender 1

Male

Connector Polarity 1

Standard

Connector Angle 1

Right Angle

Connector Mount Method 1

None

Connector Impedance 1

50

Connector Series 2

SMB

Connector Gender 2

Plug

Connector Polarity 2

Standard

Connector Angle 2

Right Angle

Connector Mount Method 2

None

Connector Impedance 2

50

RF Cable Part Number

LMR-195-UF

RF Cable Type

LMR-195-UF

RF Cable Impedance

50

Length

Select length above.

Product compliance

RoHS status

Not Available

REACH status

Not Available

TSCA status

Not Available

ECCN

EAR99

For any of the above statuses that are not available, we may be able to obtain the data by contacting various compliance specialists within our supply chain. You may ask our Compliance department if that information can be obtained by clicking here to contact us
